Optical fiber fusion splicer AI 10A
- With 5-inch 800X480 high-resolution screen, is up to 300 times focus magnifications, making it easy to observe the fiber with naked eyes;6s fast splicing 15s fast heating,the working efficiency increased by 50% compared to ordinary splicing machines.
- 3 In 1 Fiber Holder suit for SM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable;Splice Loss:0.025dB(SM)、0.01dB(MM)、0.04dB(DS/NZDS);Fiber diameter:Cladding Diameter：80-150μm、Coating Diameter：100-1000μm;Fiber Cleave Length:Coating less than 250µm：8-16mm、Coating less than 250-1000µm:16mm.
- Built-In power meter (Wavelength 850nm/1300nm/1310nm/1490nm/1550nm/1625nm); Built-in Visual Fault Locator:Power:15mw,2hz flashing And Constantly Bright Mode.
- Configure it on the phone app,splicing is easy to operate.10 Languages to switch freely :English,french,Russion,Italian,Portuguese,Polish,Spanish,Thai,Arabic. splicing record storage, synchronize to the phone, the server to cloud storage unlimited.
- It is especially suitable for optical fiber and cable projects, maintenance scientific research, railway, petrochemical, electric power, military and public security and other communications fields.
