8MP Fixed Color Maker Bullet Camera (TC-C38WS 3LRA-28)
139.33 €
Përshkrim
Kjo kamerë IP 8MP Ultra HD (4K) ofron imazh shumë të detajuar, WDR 120dB dhe analitikë inteligjente për njerëz dhe automjete, duke garantuar siguri të avancuar në çdo ambient. Me IR deri në 50m, ndriçim me dritë të bardhë, Corridor Mode dhe mbrojtje IP67, është zgjidhje ideale për instalime profesionale të brendshme dhe të jashtme.
Specifications
| Category | Specification |
|---|---|
| Image Sensor | 1/2.8" CMOS |
| Minimum Illumination | Color: 0.002 Lux @ (F1.6, AGC ON); B/W: 0 Lux with IR |
| Shutter Time | 1s – 1/100000s |
| Day & Night | IR-cut filter with auto switch (ICR) |
| Smart IR | Yes |
| WDR | 120 dB |
| Signal-to-Noise Ratio | >42 dB |
| Angle Adjustment | Pan: 0–360° / Tilt: 0–90° / Rotate: 0–360° |
| Lens Type | Fixed focal lens |
| Focal Length | 2.8 mm |
| Lens Mount | M12 |
| Aperture | F1.6 (Fixed) |
| Field of View | H: 100.5° / V: 56.5° / D: 113.0° |
| DORI Distance | Detect: 77 m / Observe: 30.5 m / Recognize: 15.5 m / Identify: 7.5 m |
| IR LEDs | 2 |
| IR Distance | Up to 50 m |
| White LEDs | 2 |
| White Light Distance | Up to 15 m |
| Video Compression | S+265 / H.265 / H.264B / H.264M / H.264H / MJPEG |
| Video Bit Rate | 32 kbps – 16 Mbps |
| Audio Compression | G.711A / G.711U / ADPCM_D / AAC_LC |
| Audio Sampling Rate | 8 kHz / 32 kHz / 48 kHz |
| Maximum Resolution | 8 MP (3840 × 2160 @ 20 fps) |
| Main Stream | PAL/NTSC up to 30 fps (multi-resolution support) |
| Sub Stream | PAL/NTSC up to 30 fps |
| Third Stream | PAL/NTSC up to 30 fps |
| BLC / HLC | Yes / Yes |
| AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto / Semi-Auto / Manual / Presets |
| ROI | 8 rectangular static areas |
| Corridor Mode | Yes |
| OSD | Up to 5 regions, max. 127 characters |
| Picture Overlay | 1 × BMP image (200 × 200) |
| Privacy Mask | 4 static black areas |
| Defog | Yes |
| General Alarms | Motion Detection, Mask Alarm |
| Exception Alarms | Voltage, Disk Error, IP/MAC Conflict, Network Disconnection |
| Linkage Method | Email, Sound, Recording, Capture, Notify Center |
| Video Analytics | Human & Vehicle Classification, Tripwire, Perimeter |
| Behavior Analysis Rules | Up to 8 per scene |
| ANR | Yes |
| Network Protocols | RTSP, RTMP, HTTP/HTTPS, TCP/UDP, SNMP, DHCP, DNS, IPv4/IPv6, SSH, FTP, SFTP |
| System Compatibility | ONVIF (Profile S/T/G/M), SDK, CGI, Milestone |
| Remote Connection | ≤ 2 users |
| Client Software | Easy7 VMS |
| Mobile Client | EasyLive Plus |
| Network Interface | 1× RJ-45 (10/100 Base-T) |
| Built-in Microphone | Yes |
| Reset Button | Yes |
| On-board Storage | microSD / microSDHC / microSDXC up to 512 GB |
| RTC | Yes |
| Operating Temperature | -35°C to 65°C |
| Operating Humidity | ≤95% RH |
| Power Supply | DC 12V ±25%, Max. 6.5W; PoE IEEE 802.3af, Max. 8W |
| Protection | Surge 4000V, ESD 6000V, IP67 |
| Dimensions | 161 × 68 × 66 mm |
| Package Dimensions | 215 × 95 × 120 mm |
| Gross Weight | 0.635 kg |
