Main Features:
– UP to 800m Wireless Communication Range(in the open space) – Hub with 12-Hour Lithium Backup Battery if AC failure – Hub with
Ethernet & LTE & WiFi Triple Channels – Support CMS Client and Local WEBIE Management And Connectivity
– Smart Hub central unit controlled by smartphone App with integrated battery
– RF Supervision: The real-time status of accessory can also be checked in the APP, such as signal, battery, tamper status, etc
– High definition surveillance cameras
– Indoor and outdoor siren.
– CID&SIA protocol for remote monitoring center
– Protected against jamming attempts (FHSS Technology)
– OTA upgraded online
Ethernet & LTE & WiFi Triple Channels – Support CMS Client and Local WEBIE Management And Connectivity
– Smart Hub central unit controlled by smartphone App with integrated battery
– RF Supervision: The real-time status of accessory can also be checked in the APP, such as signal, battery, tamper status, etc
– High definition surveillance cameras
– Indoor and outdoor siren.
– CID&SIA protocol for remote monitoring center
– Protected against jamming attempts (FHSS Technology)
– OTA upgraded online
Specification
|
Product Name
|
Smart Home Alarm System
|
|
Model Number
|
ZA8100
|
|
Network
|
Supports RJ45, WiFi, 4G
|
|
LTE-FDD
|
b1/b3/b5/b7/b8/b20
|
|
Cellular Network Format
|
GSM EGSM900MHz DCS1800MHZ
|
|
Wireless frequency
|
FSK868/433mhz
|
|
Anti Jamming
|
FHSS Anti interference
|
|
Material
|
Anti Fire ABS
|
|
Wireless Distance
|
800m(in the open space)
|
|
Defense zone
|
100
|
|
Remote Controller
|
32
|
|
RFID Card
|
64
|
|
Room Number
|
64
|
|
Administering User
|
64
|
|
Application Scenarios
|
64
|
|
Keypad User
|
64
|
|
Monitoring Center
|
SIA DC-09, CID, AES Data encryption Transmission Optional
|
|
Partition
|
32
|
|
Communication Encryption Method
|
AES 128
|
|
Alarm Sound
|
80dB
|
|
Sub device hopping time
|
36-128s
|
|
Power Supplier
|
DC12V
|
|
Product Size
|
164*164*35mm
|
|
Implementation Standrads
|
CE, EN50131-2
|
