Name: DSP Processor DSP240
Brand: TrueWave
SKU: TW064
Price: 461.09 EUR
Availability: InStock

DSP Processor DSP240

461.09 €

2 In/4 Out DSP processor, built-in EQ, three way crossover, DSP, Effector, Limiter

Koha e arritjes së produktit : Nën 6, 2026 - Nën 9, 2026

Kodi i produktit : TW064 Kategori: TrueWave Brand: TrueWave

Description	Specification
Product Type	Digital Audio Processor (DSP)
Analog Inputs	4 × XLR Balanced
Input Impedance	>10kΩ
Analog Outputs	8 × XLR Balanced
Output Impedance	50Ω
THD+N	0.002% @1kHz, 0dBu
Signal to Noise Ratio (S/N)	<100dBA
Frequency Response	20Hz – 30kHz (-0.5dBu @20Hz and 20kHz)
AD/DA Converter	24-bit / 48kHz
DSP Gain Range	-40dBu deri +15dBu me rezolucion 0.1dBu
PEQ (Parametric EQ)	8 PEQ për kanal
PEQ Types	Hi/Lo Shelving, HP/LP, Band Pass, Notch, All Pass Filters
PEQ Gain Adjustment	-30dBu deri +15dBu me hapa 0.1dBu
Filter Types	Butterworth, Bessel, Linkwitz Riley
Filter Slope	12dB deri 48dB për oktavë
PEQ Frequency Range	0.05 – 3 Octaves (Q=0.404 – 28.852)
Crossover Filter	HP/LP për çdo kanal dalje
Input Compressor (RMS)	Threshold -20dBu deri +20dBu / Bypass
Compressor Attack Time	0.3ms – 200ms
Compressor Release Time	0.3s – 3s
Output Peak Limiter	Threshold -20dBu deri +20dBu / Bypass
Limiter Attack Time	1ms – 900ms
Limiter Release Time	0.3s – 5s
Input/Output Polarity	Normal 0° ose Inverted 180°
Mute Control	ON/OFF për hyrje dhe dalje
Delay Function	0 – 1000ms për kanal hyrës dhe dalës
Preset Memory	24 Presets të përdoruesit
Connectors	4 × XLR Input, 8 × XLR Output, USB Front Panel, RS232 9-pin Rear Panel
Power Supply	AC 90V–240V, 50/60Hz
Rack Size	1RU
Dimensions	484 × 44 × 222 mm
Weight	4 kg

Përshkrim
Specifications

Përshkrim

Procesor audio profesional Digital Audio Processor (DSP) për sisteme të avancuara PA (Public Address), BGM, konferenca, ambiente komerciale dhe instalime profesionale audio. Pajisja ofron përpunim të plotë të sinjalit audio me kontroll të detajuar të EQ, crossover, compressor, limiter, delay dhe menaxhim të kanaleve hyrëse/dalëse.

Specifications

Description	Specification
Product Type	Digital Audio Processor (DSP)
Analog Inputs	4 × XLR Balanced
Input Impedance	>10kΩ
Analog Outputs	8 × XLR Balanced
Output Impedance	50Ω
THD+N	0.002% @1kHz, 0dBu
Signal to Noise Ratio (S/N)	<100dBA
Frequency Response	20Hz – 30kHz (-0.5dBu @20Hz and 20kHz)
AD/DA Converter	24-bit / 48kHz
DSP Gain Range	-40dBu deri +15dBu me rezolucion 0.1dBu
PEQ (Parametric EQ)	8 PEQ për kanal
PEQ Types	Hi/Lo Shelving, HP/LP, Band Pass, Notch, All Pass Filters
PEQ Gain Adjustment	-30dBu deri +15dBu me hapa 0.1dBu
Filter Types	Butterworth, Bessel, Linkwitz Riley
Filter Slope	12dB deri 48dB për oktavë
PEQ Frequency Range	0.05 – 3 Octaves (Q=0.404 – 28.852)
Crossover Filter	HP/LP për çdo kanal dalje
Input Compressor (RMS)	Threshold -20dBu deri +20dBu / Bypass
Compressor Attack Time	0.3ms – 200ms
Compressor Release Time	0.3s – 3s
Output Peak Limiter	Threshold -20dBu deri +20dBu / Bypass
Limiter Attack Time	1ms – 900ms
Limiter Release Time	0.3s – 5s
Input/Output Polarity	Normal 0° ose Inverted 180°
Mute Control	ON/OFF për hyrje dhe dalje
Delay Function	0 – 1000ms për kanal hyrës dhe dalës
Preset Memory	24 Presets të përdoruesit
Connectors	4 × XLR Input, 8 × XLR Output, USB Front Panel, RS232 9-pin Rear Panel
Power Supply	AC 90V–240V, 50/60Hz
Rack Size	1RU
Dimensions	484 × 44 × 222 mm
Weight	4 kg
