H.265 24HDD 160ch NVR (TC-R324160)

Spec: E/B/N/C/V2.0


HD Input
• S 265/H.265/H.264 video formats
• Connectable to the third-party network cameras
• Support live view, storage, and playback of the
connected camera at up to 12MP resolution
HD Output
• HDMI and VGA independent outputs
• HDMI Video output at up to 4K resolution
HD Storage
•24 SATA interface, up to 10TB for 1 HDD
• S 265 compression effectively reduces the storage
space and costs by up to 75%
HD Transmission
• 4×RJ45 self-adaptive 10/100/1000 Mbps network
Stability assurance
• Hot swap HDD
Various Applications
• Centralized management of IP cameras, including
configuration, information import/export, real-time
information display, upgrade, etc.
• Connectable to smart IP cameras from Tiandy and the
recording, playing back, and backing up of VCA alarms
can be realized
• VCA detection alarm is supported
• Web6 supports plug-in free browsing and can preview
videos on all browsers
• Support cloud upgrade

Kodi i produktit : 7472 Kategori: ,
Video and Audio
Access Channel 160
Incoming Bandwidth 800Mbps
Outgoing Bandwidth 400Mbps
Resolution 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Preview decoding   capability 16MP*3,12MP*4,8MP*7,6MP*9,5MP*11,4MP*14,3MP*18,1080P*28,720P*56,4CIF*80
Playback decoding   capability 16MP*3,12MP*4,8MP*6,6MP*8,5MP*9,4MP*12,3MP*16,1080P*16,720P*16
Video Output independent HDMI1   and HDMI2 outputs
simultaneous HDMI1 and VGA1 outputs
HDMI Output HDMI:800*600(60Hz),1024*768(60Hz),1280*720(50Hz/60Hz),1280*800(60Hz),
VGA Output VGA:800*600(60Hz),1024*768(60Hz),1280*720(50Hz/60Hz),1280*800(60Hz),
Multi-screen   Display 1/2/3/4/5/6/7/8/9/10/12/13/16/20A/20B/25/32/36/40/64/80
Third-party Camera   Access ONVIF;RTSP
Audio Input 1-ch,3.5mm
Audio Output 1-ch,3.5mm
Two-Way Audio 1-ch,3.5mm,using   the audio input
Liveview display Independent Output:
HDMI1/VGA1: 1/2/3/4/5/6/7/8/9/10/12/13/16/20A/20B/25/32/36/40/64/80
HDMI2: 1/2/3/4/5/6/7/8/9/10/12/13/16/20A/20B/25/32/36/40/64/80
Video S+265;H.265;S+264;H.264
Audio G711A;G711U;AAC;ADPCM_DIV4
Stream Type Video;Video &   Audio


Mobile Phone Access Android;iOS;P2P_A
System   Compatibility ONVIF(profile   T/S/G);CGI;SDK
Web IE10+;Firefox52+;Edge89+;Safari11+;Chrome57+
Record Playback
Multi-channel   Playback 16
Record Mode Manual   recording;alarm recording;Schedule recording
Storage Local HDD/USB storage   device/eSATA
Backup USB storage device
Playback Function Play/Pause/Stop/Slow/Speed/Backwards   30s/Forwards 30s/Full screen/backup (video Editing)/Step/Digital Zoom
General Alarm Motion;Mask   Alarm;Alarm Input(IPC);Video Loss;Alarm Input(NVR);Manual Alarm
Alert Alarm IP Conflict;MAC   Conflict;Network Disconnected;No disk;Illegal Access;Disk group space   alert;Disk Full;Disk R/W error;Video Abnormal;

Abnormal found in smart of disk;Abnormal temperature of the disk;Hot-spare Exception;Array Exception;IPC   voltage abnormal;RTC failure

Intelligent   Analytics
VCA Detection by   Camera Tripwire;Double   Tripwire;Perimeter;Object Abandon;Object Missing;Loiter;Running;
Parking;Heatmap;Lens Dignose;Scene Switch Dignose;Signal Abnormal Detection;
Signal Loss Detection;Plate License Recognition;On Duty Detection;Crowd   Detection;
Parking guard;Safety Helmet Detection;Electric vehicle testing;People Counting;Link To Tracking;Fireworks detection;Environmental temperature   measurement;Face Detection;

Human body temperature measurement;Advanced   Intelligence

VCA Search Heatmap;Early-warning   search;Behavior Search;Plate license search;Search safety   helmet;Thermographic retrieval;Duty search;Electric vehicle retrieval;Facial   search
Face Detection by   Camera
Performance N/A
Face Attributes Gender;age;glasses;mouth   mask;Body temp.
Face Picture   Library Up to 300 face   libraries
Up to 100000 base images
Face Picture Comparison Cooperate with   facial recognition machine
External Port
HDD 24 SATA ports,up to   18 TB for a single HDD. The maximum HDD capacity varies with environment   temperature
Disk Group 16 Disk Group
USB 2*USB2.0;1*USB3.0
HDMI 2*HDMI(supports up   to 4K resolution output)
RJ-45 4*RJ-45,10/100/1000   Mbps self-adaptive Ethernet port
SATA 24 SATA interface
RS232 1*RS232
RS485 2*RS485
Alarm I/O 16channel   in;8channel out
POE Interface N/A
POE Gross Power N/A
Power per POE Port N/A
Max Current per POE   Port N/A
General Parameter
UI Language Simple   Chinese;Traditional Chinese;English;Spanish;Korean;Italian;Turkish;Russian;
Power Supply 100~240V AC;Redundant   power supply
Power Consumption <45W(HDD not included,idling)
NetWeight 15.2Kg
GrossWeight 20Kg
Boundary Dimensions 530(L)484.5(W)174.5(H)mm
Package Dimensions 780(L)710(W)330(H)mm
Operating   Temperature -10℃~+55℃
Operating Humidity 10%~90%RH
Storage Temperature -10℃~+55℃
Storage Humidity 10%~90%RH
Package Kit Network Video   Recorder;Screw pack;Mouse;European standard power cord
