H.265 2HDD 10ch NVR (TC-R3210)


TC-R3210
Spec:I/B/K/V3.1

227.56

DATASHEET

KEY FEATURES

HD Input
• S 265/H.265/H.264 video formats
• Connectable to the third-party network cameras
• Support live view, storage, and playback of the
connected camera at up to 8MP resolution
HD Output
• 1×HDMI and 1×VGA simultaneous outputs
• HDMI Video output at up to 4K resolution
HD Storage
• 2 SATA interface, up to 10TB for 1 HDD
• S 265 compression effectively reduces the storage
space and costs by up to 75%
HD Transmission
• 1×RJ45 self-adaptive 10/100/1000 Mbps network
interface
Various Applications
• Centralized management of IP cameras, including
configuration, information import/export, real-time
information display, upgrade, etc.
• Connectable to smart IP cameras from Tiandy and the
recording, playing back, and backing up of VCA alarms
can be realized
• VCA detection alarm is supported
• Web6 supports plug-in free browsing and can preview
videos on all browsers
• Support cloud upgrade

Kodi i produktit : 7882 Kategori: ,
Video and Audio
Access Channel 10
Incoming Bandwidth 160Mbps
Outgoing Bandwidth 64Mbps
Resolution 8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Preview decoding   capability 8MP*2,6MP*2,5MP*3,4MP*4,3MP*5,1080P*8,720P*10,4CIF*10
Playback decoding   capability 8MP*2,6MP*2,5MP*3,4MP*4,3MP*5,1080P*8,720P*10
Video Output simultaneous HDMI   and VGA outputs
HDMI Output HDMI:1024*768(60Hz),(720P)1280*720(50Hz/60Hz),1280*800(60Hz),1440*900(60Hz),
(1080P)1920*1080(50Hz/60Hz),(2K)2560*1440(30Hz),(4K)3840*2160(30Hz)
VGA Output VGA:1024*768(60Hz),(720P)1280*720(50Hz/60Hz),1280*800(60Hz),1440*900(60Hz),
(1080P)1920*1080(50Hz/60Hz)
Multi-screen   Display 1/2/3/4/5/6/7/8/9/10
Third-party Camera   Access ONVIF;RTSP
Audio Input 1-ch,3.5mm
Audio Output 1-ch,RCA (Linear,1   KΩ)
Two-Way Audio 1-ch,3.5mm,using   the audio input
Liveview display Simultaneous   Output:
VGA: 1/2/3/4/5/6/7/8/9/10HDMI: 1/2/3/4/5/6/7/8/9/10
Compression
Video S+265;H.265;S+264;H.264
Audio G711A;G711U;AAC;ADPCM_DIV4
Stream Type Video;Video &   Audio
Network
Network Protocol 802.1X;ARP;DDNS;DHCP;DNS;Easy   DDNS;FTP;HTTP;HTTPS;ICMP;IGMP;IPv4;IPv6;
Multicast;NFS;NTP;PPPoE;RTCP;RTP;RTSP;SMB/CIFS;SMTP;SNMP;SRTP;SSH;SSL;
TLSv1.2,TLSv1.3;TCP/IP;UDP;Unicast;UPnP
Mobile Phone Access Android;iOS;P2P_A
System   Compatibility ONVIF(profile   T/S/G);CGI;SDK;Milestone
Web IE10+;Firefox52+;Edge89+;Safari11+;Chrome57+
Record Playback
Multi-channel   Playback 16
Record Mode Manual   recording;alarm recording;Schedule recording
Storage Local HDD/USB   storage device
Backup USB storage device
Playback Function Play/Pause/Stop/Slow/Speed/Backwards   30s/Forwards 30s/Full screen/backup (video Editing)/Step/Digital Zoom
Alarm
General Alarm Motion;Mask   Alarm;Alarm Input(IPC);Video Loss;Alarm Input(NVR);Manual Alarm
Alert Alarm IP Conflict;MAC Conflict;Network Disconnected;No disk;Illegal Access;Disk group space   alert;Disk Full;Disk R/W error;Video Abnormal;

Abnormal found in smart of  disk;Abnormal temperature of the disk;Hot-spare Exception;IPC   voltage abnormal;RTC failure

Intelligent   Analytics
VCA Detection by   Camera Tripwire;Double   Tripwire;Perimeter;Object Abandon;Object Missing;Loiter;Running;
Parking;Heatmap;Lens Dignose;Scene Switch Dignose;Signal Abnormal Detection;
Signal Loss Detection;On Duty Detection;Crowd Detection;Safety Helmet   Detection;
People Counting;Link To Tracking;Face Detection;Human body temperature   measurement
VCA Search Heatmap;Early-warning   search;Behavior Search;Thermographic retrieval;Duty search;Facial search
Face Detection by   Camera
Performance N/A
Face Attributes N/A
Face Picture   Library N/A
Face Picture   Comparison N/A
External Port
HDD 2 SATA ports,up to   10 TB for a single HDD. The maximum HDD capacity varies with environment   temperature
Disk Group 2 Disk Group
RAID N/A
eSATA N/A
USB 2*USB2.0
HDMI 1*HDMI(supports up   to 4K resolution output)
VGA 1*VGA
RJ-45 1*RJ-45,10/100/1000   Mbps self-adaptive Ethernet port
SATA 2 SATA interface
RS232 N/A
RS485 N/A
Alarm I/O 4channel   in;1channel out
POE
POE Interface N/A
POE Gross Power N/A
Power per POE Port N/A
Max Current per POE   Port N/A
General Parameter
UI Language Simple   Chinese;Traditional Chinese;English;Spanish;Korean;Italian;Turkish;Russian;Thai;

French;Polish;Dutch;Hebrew;Arabic;Vietnamese;German;Ukrainian;Portuguese;Albanian

Power Supply DC12V 3.3A
Power Consumption <10W(HDD not   included,idling)
NetWeight 1.6 kg
GrossWeight 3kg
Boundary Dimensions 341(L)273(W)47(H)mm
Package Dimensions 415(L)140(W)375(H)mm
Operating   Temperature -10℃~+55℃
Operating Humidity 10%~90%RH
Storage Temperature -10℃~+55℃
Storage Humidity 10%~90%RH
Package Kit Network Video   Recorder;Screw pack;Mouse;Power adapter;European standard power cord
