UniFi Switch US-8-60W


 US-8-60W

DATASHEET

  • 8 x RJ-45 Gigabit Ethernet Ports
  • 4 x Auto-Sensing 802.3af PoE Ports
  • 8 Gbps Non-Block Throughput
  • 16 Gbps Switching Capacity
  • 11.9 Mpps Forwarding Rate
  • 12 W Maximum Power Consumption
  • UniFi Controller Administration Softwar



123.30

The fully manageable US-8-60W UniFi 8-Port Gigabit PoE Compliant Managed Switch from Ubiquiti Networks features 8 Gigabit Ethernet ports in a small form factor offering improved performance and intelligent switching capabilities for expanding networks. In addition to the 8 Gigabit Ethernet ports, this switch offers 8 Gbps non-blocking throughput, a 16 Gbps switching capacity, and a 11.9 mpps forwarding rate. It also delivers up to 15.4W of power per PoE port.

Once installed, this UniFi switch can be managed using Ubiquiti’s own UniFi Controller software giving network administrators the ability to manage multiple sites from a single interface. Network admins have full access to various Ubiquiti devices within the network with the ability to change operating modes, monitor the status of each device, manage spanning tree configuration, and much more.

Key Specs
Inputs/Outputs
4x RJ45 Gigabit Ethernet
4x RJ45 Gigabit Ethernet PoE (15.4 W, 802.3af)
Switching Bandwidth
16 Gb/s
8 Gb/s (Non-Blocking)
PoE Power Budget
61.6 W
Performance
Forwarding Rate
11.9 Mpps
Switching Bandwidth
16 Gb/s
8 Gb/s (Non-Blocking)
Electrical
PoE per Port
15.4 W
PoE Power Budget
61.6 W
Power Draw
12.00 W (Active)
Power Supply Type
External
Environmental
Operating Temperature
23 to 113°F / -5 to 45°C
Operating Humidity
5 to 95%
General
Certifications
No
Material of Construction
Steel
Indicator Lights
Yes
Rack Mountable
No
Dimensions
5.8 x 3.9 x 1.2″ / 14.8 x 10 x 3.1 cm
Weight
1 lb / 454 g
Packaging Info
Package Weight
2.2 lb
Box Dimensions (LxWxH)
8.7 x 5.4 x 3.35″
