Product description
ZXA10 C320 is a compact design access optical platform with small capacity. Support xPON access and smooth evolution. ZXA10 C320 allows connect up to 4096 ONT/ONU with power consuption less then 200W.
Technical description
| Basic features | |
|---|---|
| Backplane capacity: | 420 Gbit/s |
| Switching capacity | 84 Gbit/s |
| Number of service cards | 2 (GPON/P2P/XG-PON1) |
| Number of combined control cards | 2 |
| Number of power supply cards | 1 |
| Number of uplink cards | 1 (10GE/GE/FE/E1/T1) |
| Maximum number of GPON subscribers | 4096 |
| Management Interfaces | CLI, SSH, SNMP, telnet |
| Dimensions | 2U (86,1 x 482,6 x 270 mm) |
| Power | -48 V (DC), 230V (AC) |
| Working temperature and humidity | -25°C – 55°C, 5% – 95% |
| GPON ITU G.984.x features | |
| Split Ratio | up to 1:128 |
| Range | 20-60 km |
| Maximum attenuation | SFP B 28 dB, SFP C 32 dB |
| Dynamic Bandwidth Allocation | NSR-DBA, SR-DBA |
| Support | FEC, AES128, SCB, OLS |
| L2/L3 Features | |
| Multicast | IGMP Snooping/Proxy/SPR a MLD Snooping/Proxy, 256 multicast VLAN, CAC, PRV, CDR |
| QoS | 8 queues/port, SP, DWRR, DSPC (re)mark, CIR, PIR, EIR |
| Security features | L2-L4 ACL, IP a MAC source guard, DOS protection, MAC/IP anti-spoofing, Anti-flooding, DHCP 82 |
| Features | VLAN, SVLAN, QinQ, VLAN Stacking, STP/RSTP/MSTP, DHCP Server, DHCP Relay, DHCP Proxy, IPv4/IPv6 dual stack |
| Cards specification | |
| Control, uplink and power supply cards | SMXA/1 – 3 x GE uplink interface (1x RJ45, 2x SFP), power input -48 V DC, switching power 84 Gbit/s |
| SMXA/3 – 1 x 10GE 2 x GE uplink interface (2x SFP, 1x RJ45), power input -48 V DC, switching power 84 Gbit/s | |
| Power supply cards | PRAM – Power input 230V AC, port for backup batteries, power DC output |
| GPON karty | GTGO – 8 GPON ports, split ratio up to 1:128 |
| GTGH – 16 GPON ports, split ratio up to 1:128 | |
| FTGK – 48 P2P ports (WDM) or 24 GE ports (separated fibers for uplink / downlink) |
