Product Specifications

• Power Supply: Battery: DC3V, 1×CR123A

• Wireless Protocol: FSK with Two-Way Communication

• Radio Frequency: 868MHz / 433MHz

• Transmission Range: Up to 800 meters outdoor

• Detection Angle: 90°

• Detection Range: 12m

• Pet Immunity: 35Kg

• Detectable Speed: 0.3~2m/s

• Sensitivity: 3 Level Adjustable via APP

• Detection Interval: 30~180s Adjustable (60s Default)

• Tamper Alarm: Support

• Battery Life: 5 Years (10 Times Triggered Per Day)

• Installation Method: Wall-mount with 3M or Screws

• Operating Temperature / Humidity: -1055°C / 595%RH

• Dimensions: 114.6 × 61.1 × 43.5 mm

• Compliance Standard: CE

Product Specifications

• Wireless Protocol: FSK

• Transmission Frequency: 868MHz / 433MHz

• Transmission Power: ≤12dBm

• Operating Voltage: DC3V (AA battery × 2)

• Operating Current: <80mA

• Static Current: <60μA

• Operating Temperature: -10°C ~ +55°C

• Operating Humidity: ≤95%RH, no condensation

• Alarm Sound: 80dB (3 meters in front)

• Detection Range: 50 Square Meters

• Wireless Distance: 500m (outdoor open space)

• Battery Life: 2 ~ 3 Years

• Dimensions: φ105 × 40mm

• Implementation Standard: EN14604
