SPECIFICATIONS
Camera
Image Sensor 1/2.8″CMOS
Min. Illumination Color:0.002Lux@(F1.6,AGC ON),B/W:0Lux with IR
Shutter Time 1s~1/100000s
Day&Night IR-cut filter with auto switch (ICR)
Smart IR Yes
WDR 120dB
S/N >42dB
Angle Adjustment 0~330°(P); 0~75°(T); 0~350°(R)
Lens
Lens Type Fixed focal lens
Focal Length 2.8mm
Lens Mount M12
Aperture Range F1.6
Aperture Type Fixed
Field of View 100.5°(H); 56.5°(V); 113.0°(D)
DORI Distance Detect:77m
Observe:30.5m
Recognize:15.5m
Identify:7.5m
Illuminator
IR LEDs 8
IR Distance Up to 30m
Wavelength 850nm
White LEDs 8
Whitelight Distance 10m
Compression Standard
Video Compression S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG
Video Bit Rate 32k~16Mbps
Audio Compression G.711A/G.711U/ADPCM_D/AAC_LC
Audio Sampling Rate 8kHz/32kHz/48kHz
Max. Resolution 8MP,3840×2160@20fps
Main Stream PAL:20fps(3840×2160, 3072×2048), 25fps(2560×1440, 2304×1296, 1920×1080, 1280×720)
NTSC:20fps(3840×2160, 3072×2048), 30fps(2560×1440, 2304×1296, 1920×1080, 1280×720)
Sub Stream PAL:25fps(704×576, 704×288, 640×360, 352×288)
NTSC:30fps(704×480, 704×240, 640×360, 352×240)
Third Stream PAL:25fps(704×576, 704×288, 352×288, 640×480)
NTSC:30fps(704×480, 704×240, 352×240, 640×480)
BLC Yes
HLC Yes
2025.02.28
3D DNR Yes
White Balance Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock
White Balance
ROI 8 rectangular static areas
Corridor Mode Yes
OSD Overlay of additional characters in 5 regions, 1 line, with a maximum of 127 characters or 42 Chinese
characters per region; 16*16/32*32/48*48/64*64/96*96; Vector/Lattice
Picture Overlay 1*200×200 size BMP 16 color bit image overlay
Privacy Mask 4 black static areas
Defog Yes
Feature
General Alarm Motion Detection; Mask Alarm
Exceptions Alarm Voltage Alarm; Disk Full; Disk R/W Error; IP Address Conflict; MAC Address Conflict; FTP Server
Exception ; Network Disconnection
Linkage Method Send Email; Trigger Sound; Trigger Recording; Trigger Capture; Notify Surveillance Center
Video Analytics Human/Vehicle Classification; Tripwire; Perimeter
Rules of Behavior Analyse In 1
Scene
8
Network
ANR Yes
Protocols RTSP; RTMP; HTTP; HTTPS; TCP; UDP; UPnP; ICMP; IGMP; SNMP v1\v2\v3; DHCP; DNS; DDNS; Easy
DDNS; NTP; SMTP; TLS v1.2; SSL; 802.1X; QoS; IPv4; IPv6; PPPoE; SSH; Unicast; Multicast; RTCP; ARP;
SRTP; FTP; SFTP
System Compatibility P2P(Mutually exclusive with Profile G); ONVIF(Profile S/T/G/M) ; SDK; CGI; Milestone
Remote Connection ≤2
Client Easy7 VMS
Moblie Client EasyLive Plus
Web IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
Interface
Communication Interface 1×RJ-45 (10/100 Base-T)
Built-in Mic 1×Built-in Mic
Reset Button Yes(Built-in)
On-board Storage Support microSD/microSDHC/microSDXC card,up to 512GB
RTC Yes
General
Web Client Language 20 languages
Simple Chinese/Traditional Chinese/English/Spanish/Korean/Italian/Turkish/Russian/Thai/French/
Polish/Dutch/Hebrew/Arabic/Vietnamese/German/Ukrainian/Portuguese/Albanian/Greek
Operating Temperature -35℃~65℃(-31℉~149℉)
Operating Humidity ≤95%RH
Storage Temperature -35℃~65℃(-31℉~149℉)
Storage Humidity 10%~95%RH(non-condensing)
Power Supply DC12V±25%,Max. 6W; PoE:IEEE 802.3af,Max. 7.5W
2025.02.28
Protection Surge4000V; ESD6000V; IP67; IK10
Boundary Dimensions 120(L)120(W)90(H)mm
Package Dimensions 140(L)140(W)120(H)mm
GrossWeight 0.58kg
