Përshkrim
| Casing | Polycarbonate |
| Connections | 1 Gbps SFP port DC terminal block DC RJ45 port, 4-pair DC injection 1000 Mbps Ethernet PoE port, 4-pair (24 or 50 VDC input) or 2-pair (4, 5 ; 7, 😎 (24 VDC input) PoE passthrough |
| Power Consumption | Typical: 1.5 W |
| Power Method | DC Injection From: RJ45 DC in port, 2-pair or 4-pair PoE Capability: RJ45 PoE port, 4-pair PoE capability DC terminal block |
| Input Voltage | 16 to 57 VDC |
| Protection | ESD and EM: ± 24 kV contact, Air for Ethernet |
| Certifications | CE, FCC, IC |
| Operating Temperature | -22 to 140°F (-30 to 60°C) |
| Operating Humidity | 10 to 95% non condensing |
| Dimensions | 7.7 x 3.7 x 1.3″ (196 x 93.5 x 32.4 mm) |
| Weight | 10.2 oz (288 g) |
Produkte të afërt
10G Ethernet Media Converter
MC10G
-Provide one 10 Gigabit optical port, one 10 Gigabit adaptive electrical port
-The electrical port supports 1000Base-T, 2.5/5/10GBase-T auto-negotiation
IEEE802.3x flow control supporting full duplex
-Support half-duplex back pressure flow contr
-Working wavelength 850nm, 1310nm, 1550nm optional
-Provide multiple fiber transmission modes such as dual fiber multimode,
dual fiber single mode and single fiber single mode
-Low power consumption, low heat, can work stably for a long time
