H.265 2HDD 10ch Face Recognition NVR (TC-R3210)
TC-R3210
Spec:I/F
747.80 €
HD Input
• S 265/H.265/H.264 video formats
• Connectable to the third-party network cameras
• Support live view, storage, and playback of the
connected camera at up to 6MP resolution
HD Output
• 1×HDMI and 1×VGA simultaneous outputs
• HDMI Video output at up to 1080P resolution
HD Storage
• 2 SATA interface, up to 10TB for 1 HDD
• S 265 compression effectively reduces the storage
space and costs by up to 75%
HD Transmission
• 1×RJ45 self-adaptive 10/100 Mbps network
interface
Various Applications
• Centralized management of IP cameras, including
configuration, information import/export, real-time
information display, upgrade, etc.
• 1:N face recognition
• Connectable to smart IP cameras from Tiandy and the
recording, playing back, and backing up of VCA alarms
can be realized
• VCA detection alarm is supported
• Web6 supports plug-in free browsing and can preview
videos on all browsers
• Support cloud upgrade
| Input | |
| Video Input | 10-ch |
| Max Resolution | 6MP |
| Two-way Audio Input | 1-ch, 3.5mm |
| Bandwidth | Income 80Mbps; Outgoing 80Mbps |
| Output | |
| HDMI/VGA Output | HDMI 1-ch, 1920×1080, 1280×720, 1024×768, 1366×768, 1440×900, 1280×800 |
| VGA 1-ch, 1920×1080, 1280×720, 1024×768, 1366×768, 1440×900, 1280×800 | |
| Screen Split | 1/3/4/5/6/7/8/9/10 |
| Audio Output | 1×RCA |
| Decoding | |
| Decoding Format | S+265/H.265/H.264 |
| Recording Resolution | 6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Preview Capability | 1×6MP, 1×5MP, 1×4MP, 2×3MP, 3×1080P, 6×720P |
| Synchronous Playback | 1×6MP, 1×5MP, 1×4MP, 2×3MP, 3×1080P, 6×720P |
| Records Encryption | Yes |
| Hard Disk | |
| SATA | 2 SATA interface for 2 HDDs |
| Capacity | Up to 10TB for each HDD |
| eSATA Interface | N/A |
| Array Type | N/A |
| External Interface | |
| Network Interface | 1×RJ45 self-adaptive 10/100/100 Mbps network interface |
| USB Interface | 2×USB 2.0 |
| Serial Interface | N/A |
| Alarm In/Out | 0/1 |
| Face Recognition | |
| Base Libraries | 32 |
| Face Pictures | 10,000 |
| Video Stream for Recognition | 1 |
| Picture Stream for Recognition | 10 |
| Face Picture Search | Yes |
| Network | |
| Protocol | HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, DHCP, DNS, DDNS, EasyDDNS, NTP, SMTP, SSL, QoS, IPv4, IPv6, IP Filter, Telnet, SSH, RTSP, RTP, RTCP, ARP |
| System Compatibility | ONVIF, SDK, P2P |
| General | |
| Web Version | Web6 |
| Language | Chinese, English |
| Operating Conditions | -10～55℃, 10%~90% RH |
| Power Supply | DC12V 3.3A |
| Consumption (without HDD) |
≤10W |
| Chassis | 1U |
| Dimensions | 47.1×272.6×341mm, (1.85×10.73×13.43 inch) |
| Weight (without HDD) | 1.6Kg (3.53lb) |
