DESCRIPTION
Rated temperature:70℃
Reference standard:UL Subject 444, EIA/TIA 568B.2-10 & ISO/IEC 11801
Solid bare copper conductor
Colour-coded PE insulation
Rip cord (optional
PVC or LSZH jacket
APPLICATION
100 Base-T4
100Base-TX
100VG-AnyLAN
155Mbps ATM
622Mbps ATM
CONSTRUCTION
U/UTP
Number of Pairs
4 Pair
AWG
24AWG
Conductor Dimension (mm)
0.495±0.005mm
Solid or Stranded;
Bare or Tinned
Solid Bare Copper
Insulation material
HDPE
Insulation Dimension [mm)
0.87±0.05mm
Operating Temp. Range
-20~70℃
Max. Recommended
110N
Flame Test
CMR
