DESCRIPTION
Rated temperature:70℃
Reference standard:UL Subject 444, EIA/TIA 568B,
2-1& ISO/IEC 11801, IEC 61161
Solid bare copper conductor
Colour-coded PE insulation
Rip cord (optional)
PVC or LSZH jacket
APPLICATION
100 Base-T4
100Base-TX
100VG-AnyLAN
1000Base-T
1000Base-TX
155Mbps ATM
622Mbps ATM
Construction
FTP
Number of Pairs
4 Pair
AWG
24AWG
Conductor Dimension (mm)
0.515
Solid or Stranded;
Bare or Tinned
Solid Bare Copper
Insulation material
HDPE
Operating Temp. Range
-20~70°C
Flame Test
CMR
