SPECIFICATION
>
| Features / filters | |
| Antenna type | |
| Antennas quantity | |
| Built-in processor | |
| Cables included | |
| Depth | |
| Ethernet LAN | |
| Ethernet LAN interface type | |
| Ethernet WAN | |
| Harmonized System (HS) code | |
| Height | |
| Internal memory | |
| LED indicators | |
| Manual | |
| Mobile operating systems supported | |
| Modulation | |
| Networking standards | |
| Operating relative humidity (H-H) | |
| Operating temperature (T-T) | |
| Power source type | |
| Processor architecture | |
| Processor cores | |
| Processor frequency | |
| Processor manufacturer | |
| Processor model | |
| Product colour | |
| Product type | |
| Reset button | |
| Security algorithms | |
| Storage relative humidity (H-H) | |
| Storage temperature (T-T) | |
| Top Wi-Fi standard | |
| Wi-Fi band | |
| Wi-Fi standards | |
| Width | |
| WLAN data transfer rate (max) | |
| Basic general data | |
| Brand | Xiaomi |
| Manufacturer | Mi |
| Model | AX3200 |
| Type | Wireless Router |
| Dimensions | 284mm × 186mm × 186mm |
| Product colour | Black |
| Hardware configuration | |
| Processor | MediaTek Filogic800 Dual-core A53 1.35GHz |
| Memory | 256MB |
| 2.4GHz Wi-Fi | 4×4 (supports up to IEEE 802.11n protocol, theoretical maximum speed is 800Mbps) |
| 5GHz Wi-Fi | 4×4 (supports IEEE 802.11ax protocol, theoretical maximum transmission speed is 2402Mbps) |
| Antennas | External omni-directional antennas |
| Total ports | Adaptive WAN Port 10/100/1000Mbps (Auto MDI/MDIX) ×1 Adaptive LAN ports 10/100/1000Mbps (Auto MDI/MDIX) ×3 |
| LED indicator | 2 indicator lights, of which system light × 1, Internet light × 1 |
| System reset button | ×1 |
| Mesh button | ×1 |
| Power input port | ×1 |
| Protocol standards | IEEE 802.11a/b/g/n/ac/ax IEEE 802.3/3u/3ab |
| Wireless specification | |
| Dual-band | 2.4GHz 5GHz |
| Modulation | 11b：DSSS：DBPSK(1Mbps),DQPSK(2Mbps),CCK(5.5/11Mbps) 11a/g：OFDM:BPSK(6/9Mbps),QPSK(12/18Mbps),16QAM(24/36Mbps), 64QAM(48/54Mbps) 11n：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM.256QAM. 11ac：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM. 11ax：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM. |
| Software specifications | |
| Operating System | MiWiFi ROM, a smart router operating system based on OpenWRT |
| Wi-Fi encryption | WPA-PSK/WPA2-PSK/WPA3-SAE encryption |
| Management applications | Supports Web, Android, iOS |
| Work environment | |
| Operating environment Temperature | 0-40℃ |
| Operating humidity | 10%-90%RH (non-condensing) |
| Storage temperature | -40-70℃ |
| Storage Humidity | 5%-90%RH (non-condensing) |
