Network Video Recorder Pro (UNVR-Pro)
UNVR-Pro
Përshkrim
A 2U-sized video recorder with (7) 2.5/3.5″ HDD bays that can provide up to 60 days of storage for (24) 4K cameras or (70) Full HD cameras.
Specifications
| Parameter | Specification |
|---|---|
| Overview | |
| Dimensions | 442 × 325 × 87 mm (17.4 × 12.8 × 3.4") |
| Form Factor | Rack mount (2U) |
| UniFi Application Suite | Protect ✓ / Access ✓ |
| Door Access Support | Yes |
| Vantage Point | Yes |
| Data Protection | Yes |
| NDAA Compliant | Yes |
| Capacity & Performance | |
| Managed Cameras | 70× HD / 35× 2K / 24× 4K |
| Managed Access Hubs | Up to 150 |
| Storage Capacity | 7 × 3.5" drive bays |
| Hard Drive Support | 2.5" / 3.5" HDD & SSD |
| Networking Interfaces | |
| Network Ports | 1 × 10G SFP+ / 1 × GbE RJ45 |
| Management Interface | Ethernet |
| Power & Redundancy | |
| Power Redundancy | Yes |
| Power Method (AC) | Universal AC input, 100–240V AC, 3A Max., 50/60 Hz |
| Power Method (DC) | USP-RPS DC input, 11.5V DC, 13.91A |
| Power Supply | Internal AC/DC, 200W |
| Max Power Budget for Drives | 135 W |
| Max Power Consumption | 160 W |
| Hardware | |
| Processor | Quad-core ARM® Cortex®-A57 @ 1.7 GHz |
| Memory | 8 GB |
| Display | 1.3" touchscreen |
| Mechanical | |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Weight (without brackets) | 9.2 kg (20.3 lb) |
| Weight (with brackets) | 9.5 kg (20.8 lb) |
| Environment | |
| Operating Temperature | −5 to 40 °C (23 to 104 °F) |
| Operating Humidity | 5% to 95% non-condensing |
| Certifications | |
| Certifications | CE, FCC, IC, Anatel (06697-21-08356) |
