UniFi 24 Port PoE Pro Switch


USW-Pro-24-POE

DATASHEET

  • 24 x Gigabit Ethernet Ports
  • 16 x PoE+ Ports | 8 x PoE++ Ports
  • 2 x 10 Gb/s SFP+ Ports
  • 88 Gb/s Switching Capacity
  • 65.47 Mpps Forwarding Capacity
  • Rack-Mountable Design
  • 1.3″ Touchscreen Display
  • Passive Cooling
  • UniFi Controller Compatible



742.27

Expand your business’s network with the fully manageable second-generation UniFi Pro PoE 24-Port Gigabit Managed PoE Network Switch with SFP+ from Ubiquiti. Designed with Layer 3 protocol support, the passively cooled 24-port Gigabit switch features a total power budget of 400W across 16 32W PoE connectors and eight 64W PoE++ ports for power-intensive devices such as high-resolution network security cameras. Each port delivers 44 Gb/s non-blocking throughput with a 88 Gb/s switching capacity and a 65.47 Mpps forwarding rate. Two 10 Gb/s SFP+ ports are available for additional network expansion using compatible devices. Administrators may monitor and manage the switch with the 1.3″ touchscreen display or access and configure it and connected devices using the UniFi Network Controller application.



Kodi i produktit : 2858 Kategori: , , ,
Key Specs
Inputs/Outputs
16x RJ45 Gigabit Ethernet WAN PoE+ (30 W, 802.3at)
8x RJ45 Gigabit Ethernet WAN PoE+ (30 W, 802.3at)
2x SFP+ 10 GbE WAN
Switching Bandwidth
44 Gb/s (Non-Blocking)
PoE Power Budget
400 W
Protocols
Layer Services Supported
Layer 2, Layer 3
Supported Protocols
Auto-MDIX/MDI
Port Mirroring
Performance
Forwarding Rate
65.47 Mpps
Switching Bandwidth
44 Gb/s (Non-Blocking)
Electrical
PoE per Port
32 to 64 W
PoE Power Budget
400 W
Power Draw
50.00 W (Max)
DC Input Power
11.5 to 52 VDC at 7.69 A
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Power Supply Type
Internal
Environmental
Operating Temperature
27 to 72°F / -5 to 40°C
Operating Humidity
10 to 90%
General
Certifications
CE, FCC, IC
Cooling System
Passive
Indicator Lights
Yes
Rack Mountable
Yes 1 RU
Dimensions
17.42 x 11.24 x 1.72″ / 442.4 x 285.4 x 43.7 mm
Weight
9.48 lb / 4.3 kg
Packaging Info
Package Weight
12.69 lb
Box Dimensions (LxWxH)
20.5 x 15.8 x 4.9″
