UniFi Switch Enterprise 8 8-Port 2.5Gb PoE+ Compliant Managed Network Switch with SFP+

USW-ENTERPRISE-8-POE

  • 8 x 2.5Gb Ethernet PoE+ Ports
  • 2 x 10Gb SFP+ Ports
  • 80 Gb/s Switching Capacity
  • 59.52 Mpps Forwarding Rate
  • Desktop & Wall-Mountable Design
  • 120W Power Budget
  • 1.3″ LCM Touchscreen with AR Management
  • Works with UniFi Network Application



Grow your business’s network to support power over Ethernet compatible devices such as security cameras, VoIP phones, access points, and more with the UniFi Switch Enterprise 8 8-Port 2.5Gb PoE+ Compliant Managed Network Switch from Ubiquiti Networks. This managed switch features eight high-speed 2.5Gb Ethernet ports, each supporting up to 32W of power with a total budget of 120W. There are also two 10Gb SFP+ ports for fiber uplinks. Designed to blend into its environment, you can use the included hardware to mount the UniFi Switch Enterprise 8 on a wall or flat surface, where it will operate silently without causing a disturbance. Use the convenient 1.3″ LCM color touchscreen to quickly configure, monitor, and troubleshoot your connections. Or you can manage your switch from almost anywhere using the UniFi Network app, which also includes an augmented reality feature that provides you with a visual overview of your port connections.

Performance
The UniFi Switch Enterprise 8 supports features an 80 Gb/s (40 Gb/s non-blocking) switching capacity and 59.52 Mpps forwarding rate to help ensure fast, smooth, and reliable data transfers. Layer 3 switching protocols will become available in a future update.
Kodi i produktit : 6387 Kategori: , ,
Interfaces
Inputs/Outputs 8 x 2.5 Gb/s Ethernet (RJ45) PoE
2 x 10Gb SFP
Protocols
Layer Services Supported Layer 2 Support, Layer 3 Support
Standards
Supported IEEE Standards 802.3af, 802.3at
Performance
Forwarding Rate 59.52 Mpps
Switching Bandwidth 80 Gb/s
40 Gb/s (Non-Blocking)
Electrical
DC Input Power 52 to 115 VDC
AC Input Power 100 to 240 VAC, 50 / 60 Hz at 2 A
PoE Power Budget 120 W
PoE per Port 32 W
Power Supply Type Internal
Environmental
Operating Temperature 27 to 72°F / -5 to 40°C
Operating Humidity 10 to 90%
General
Cooling System Passive
Material of Construction Plastic
Indicator Lights Link/Activity
Dimensions 9.8 x 7.9 x 1.7″ / 248 x 200 x 44 mm
Weight 5.3 lb / 2.4 kg
Packaging Info
