Specification

• Dimensions 205 x 83 x 37 mm
• Weight 250 g (without Antennas) 294 g (with Antennas)
• Networking Interface (2) 10/100 Ethernet Ports
• Buttons: Reset
• Antennas: (2) External 5 dBi Omni Antennas Included, 191 mm (Length), 13 mm (Diameter)
• Wi-Fi Standards 802.11 b/g/n
• Power Method: Passive Power over Ethernet (48V), 802.3af Supported
• Power Supply: 48V, 0.5A PoE Adapter (Included)
• Maximum Power Consumption: 8 W
• 2.4 GHz and 5 GHz Maximum TX Power – 28 dBm
• BSSID Up to Four Per Radio
• Power Save Supported
• Wireless Security WEP, WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i
• Certifications CE, FCC, IC
• Mounting Wall/Ceiling (Kits Included)
• Operating Temperature -30 to 65 °C
• Operating Humidity 5 – 95% Non-Condensing

Advanced Traffic Management

• VLAN 802.1Q
• Advanced QoS Per-User Rate Limiting
• Guest Traffic Isolation Supported
• WMM Voice, Video, Best Effort, and Background
• Concurrent Clients 100+

Supported Data Rates (Mbps)

• 802.11n – 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
• 802.11b – 1, 2, 5.5, 11 Mbps
• 802.11g – 6, 9, 12, 18, 24, 36, 48, 54 Mbps

UBIQUITI DATASHEET
