UniFi In-Wall 2.4 / 5GHz AC Pro


UniFi AP, AC, In Wall, Pro

111.86

Ubiquiti Networks UAP-AC-IW-PRO is an in-wall 802.11ac Wi-Fi access point featuring (3) Gigabit Ethernet ports; (1) PoE in data port, (1) PoE out data, and (1) data only.

Product Specifications
• Dimensions: 139.7 x 86.7 x 25.75mm (5.5 x 3.41 x 1.01″)
• Weight: 210g (7.41oz)
• (3) 10/100/1000 Ethernet Ports
• Buttons: Reset
• Power Method: 802.3at PoE Supported
• Power Supply: UniFi PoE Switch (Not Included)
• Power Save: Supported
• PoE Out: 48V Pass-Through (Pins 1,2 ; 3,60)
• Maximum Power Consumption: 10W (22W w/ PoE Passthrough)
• Maximum TX Power:
2.4GHz: 22dBm
5GHz: 22dBm
• MiMO:
2.4GHz: 3×3
5GHz: 3×3
• Max Data Speed:
2.4GHz: 450Mbps
5GHz: 1300Mbps
• Max Range: 100m (328′)
• Antennas: (3) Dual-Band Antenna, Single-Polarity
2.4GHz: 5dBi
5GHz: 6dBi
• Wi-Fi Standards: 802.11a/b/g/n/ac
• Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP, AES)
• BSSID: Up to Four per Radio
• Mounting: 1-Gang Electrical Wall Box (not included)
• Operating Temperature: -10 to 50°C (14 to 122°F)
• Operating Humidity: 5 to 95% non-condensing
• Certifications: CE, FCC, IC
• VLAN: 802.1Q
• Advanced QoS: Per-User Rate Limiting
• Guest Traffic Isolation: Supported
• WMM: Voice, Video, Best Effort, and Background
• Concurrent Clients: 250

SKU: 0124 Categories: , Tag:
