Ubiquiti G5 Dome Ultra Black (UVC-G5-Dome-Ultra-B)
The Ubiquiti UVC-G5-Dome-Ultra-B is a black ultra-compact and tamper-resistant 2K HD PoE camera with night vision designed for low-profile indoor security.
Ubiquiti UVC-G5-Dome-Ultra-B Key Features:
- 2K (4MP) video resolution
- Ultra-wide viewing angle (102.4°)
- 20 m (65 ft) IR night vision
- AI event detections
- Connect and power using PoE
- Optional Flush Mount for in-ceiling installation
Ubiquiti UVC-G5-Dome-Ultra-B Technical Specifications
Mechanical
- Dimensions: Ø63.6 x 68.2 mm (Ø2.5 x 2.7″)
- Weight: 175 g (6.2 oz)
- Enclosure material: Aluminum alloy, polycarbonate
- Mount material: Stainless steel
- Resistance: IK06
Optics
- Sensor: 1/2.4″ CMOS
- Lens: Fixed focal length
- View angle: H: 102.4°, V: 54.9°, D: 120.6°
- Night mode: Built-in IR LED illumination and IR cut filter
- IR distance: 20 m (65 ft)
Video
- Resolution: 4MP 2688 x 1512 (16:9)
- Max. frame rate: 30 FPS
- Image settings: Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
System
- Processor: Dual-core Arm® Cortex®-A7 based chip
- Networking interface: 10/100 MbE RJ45 port
- Max. power consumption: 4.2W
- Power method: PoE
- Supported voltage range: 37–57V DC
- Button: Factory reset
- Mounting: Surface mount
- Ambient operating temperature: -20 to 40º C (-4 to 104º F)
- Ambient operating humidity: 10 to 90% noncondensing
- Certifications: FCC, IC, CE
Software
- Web application: UniFi Protect
- Mobile app: UniFi Protect iOS™ and Android™
