8-Port Gigabit Unmanaged Switch Metal (GS108)


A 8-GbE switch with metal casing ideal for extended Gigabit wired network expansion in home, office, and FTTB scenarios.

DATASHEET


    •  8× Gigabit Ethernet Ports
    •  Max 170m Gigabit Transmission
    •  4 Mbit Packet Buffer
    •  Max 2.75W, Idle 2.2W
    •  Desktop, Wall-Mount
    •  88×52.5×24 mm (3.46×2.07×0.94″)
    •  211 g (7.44 oz.)



16.81

Model Version GS108 4.0
Protocols 802.3 Protocols
  • 802.3x Flow Control
  • 802.3i 10 Mbps over Twisted Pair
  • 802.3u 100 Mbps over Twisted Pair
  • 802.3ab 1 Gbps over Twisted Pair
CPU Chipset EN8851F
Interfaces Gigabit RJ45 Ports 8
LED
  • Power
  • Speed/Link/ACT of Each Ethernet Port
Power Input DC Jack
Performance MAC Address Table 8192
Max Switching Capcity 16 Gbps
Max Forwading Rate 11.904 Mpps
Jumbo Frame 15 KB
Packet Buffer 4 Mbit
Power Basic Power Saving 1
Power Methods DC
DC 5V 0.55A
Max Power Consumption (W) 2.75W
Idle Power Consumption (W) 2.2W
Reliability Lightning/Surge Protection 2kV
ESD Air Protection 8kV
ESD Contact Protection 4kV
Environment Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
Package Content
  • Main Product
  • Power Adapter
  • Installation Guide
Mechanical Installation
  • Desktop
  • Wall-Mounting
Casing Material Metal
Dimension 138×78×25 mm
5.43×3.07×0.98 inches
Product Weight EU: 211 g (7.44 oz.),
