AC INPUT: AC100-240V, 50/60Hz
Ethernet Port:
8 x 10/100/1000Mbps PoE Port
2 x 1000Mbps SFP Port
1 x RJ45 Console Port
Bandwidth: 20Gbps
Packet Forwarding rate: 14.88Mpps
DDR SDRAM: 128MB
Flash Memory: 16MB
Packet Buffer Memory: 4M
MAC Address: 8K
Jumbo frame: 9.6Kbytes
VLANs: 4096
Network Protocols:
IEEE 802.3: Ethernet MAC Protocol
IEEE 802.3i: 10BASE-T Ethernet
IEEE 802.3u: 100BASE-TX Fast Ethernet
IEEE 802.3ab: 1000BASE-T Gigabit Ethernet
IEEE 802.3z: 1000BASE-X Gigabit Ethernet (optical ?ber)
IEEE 802.3ad: Standard method for performing link aggregation
IEEE 802.3x: Flow control
IEEE 802.1ab: LLDP/LLDP-MED (Link Layer Discovery Protocol)
IEEE 802.1p: LAN Layer QoS/CoS Protocol Traf?c Prioritization (Multicast ?ltering function)
IEEE 802.1q: VLAN Bridge Operation
IEEE 802.1x: Client/Server Access Control and Authentication Protocol
IEEE 802.1d: STP
IEEE 802.1s: MSTP
IEEE 802.1w: RSTP
PoE protocol:
IEEE802.3af (15.4 W)
IEEE802.3at (30 W)
Network Media
10BASE-T: Cat3, 4, 5 or above UTP(=100 M)
100BASE-TX: Cat5 or above UTP(=100 M)
1000BASE-TX: Cat5 or above UTP(=100 M)
Multi-mode Fiber: 50/125, 62.5/125, 100/140um
Single-mode Fiber: 8/125, 8.7/125, 9/125, 10/125um
Operating temperature: -20~50°C
Storage temperature: -40~85°C
Operating Humidity: 10%~90%, No condensation
Storage Humidity: 5%~90%, No condensation
Working height: Up to 10,000 feet
Storage height: Up to 10,000 feet
Indicator: PWR, SYS, SW, PoE, Link/ACT -8 Gigabit POE Ports, 2 Gigabit Combo Ports, 1 Console Port
-Compatible with IEEE802.3at and IEEE802.3af
-Ethernet port supports 10/100/1000M adaptive
-Fanless design, Natural Cooling, Compatible with 1U Rack Mount
-Support PoE Power Management, PoE watchdog
-Lightning Protection Surge: General Mode 6KV, Differential Mode 4KV, ESD 15KV
AC INPUT: AC100-240V, 50/60Hz
Ethernet Port:
8 x 10/100/1000Mbps PoE Port
2 x 1000Mbps SFP Port
1 x RJ45 Console Port
Bandwidth: 20Gbps
Packet Forwarding rate: 14.88Mpps
DDR SDRAM: 128MB
Flash Memory: 16MB
Packet Buffer Memory: 4M
MAC Address: 8K
Jumbo frame: 9.6Kbytes
VLANs: 4096
Network Protocols:
IEEE 802.3: Ethernet MAC Protocol
IEEE 802.3i: 10BASE-T Ethernet
IEEE 802.3u: 100BASE-TX Fast Ethernet
IEEE 802.3ab: 1000BASE-T Gigabit Ethernet
IEEE 802.3z: 1000BASE-X Gigabit Ethernet (optical ?ber)
IEEE 802.3ad: Standard method for performing link aggregation
IEEE 802.3x: Flow control
IEEE 802.1ab: LLDP/LLDP-MED (Link Layer Discovery Protocol)
IEEE 802.1p: LAN Layer QoS/CoS Protocol Traf?c Prioritization (Multicast ?ltering function)
IEEE 802.1q: VLAN Bridge Operation
IEEE 802.1x: Client/Server Access Control and Authentication Protocol
IEEE 802.1d: STP
IEEE 802.1s: MSTP
IEEE 802.1w: RSTP
PoE protocol:
IEEE802.3af (15.4 W)
IEEE802.3at (30 W)
Network Media
10BASE-T: Cat3, 4, 5 or above UTP(=100 M)
100BASE-TX: Cat5 or above UTP(=100 M)
1000BASE-TX: Cat5 or above UTP(=100 M)
Multi-mode Fiber: 50/125, 62.5/125, 100/140um
Single-mode Fiber: 8/125, 8.7/125, 9/125, 10/125um
Operating temperature: -20~50°C
Storage temperature: -40~85°C
Operating Humidity: 10%~90%, No condensation
Storage Humidity: 5%~90%, No condensation
Working height: Up to 10,000 feet
Storage height: Up to 10,000 feet
