1HDD 5ch PSE NVR (TC-R3105 Spec:I/B/P4/Eu/L/S/V2.0)
86.48 €
TC-R3105
Spec:I/B/P4/Eu/L/S/V2.0
Koha e arritjes së produktit : Kor 27, 2026 - Kor 28, 2026
Përshkrim
NVR me 5-kanale hyrje, mbështetje për PoE, ruajtje deri 8TB, mbështetje ONVIF dhe video 4K, kompakt dhe i lehtë.
Specifications
| Category | Specification |
|---|---|
| Access Channel | 5 |
| Incoming Bandwidth | 60 Mbps |
| Outgoing Bandwidth | 40 Mbps |
| Resolution | 8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Preview Decoding Capability | 8MP×1, 6MP×1, 5MP×1, 4MP×2, 3MP×2, 1080P×4, 720P×5, 4CIF×5 |
| Playback Decoding Capability | 8MP×1, 6MP×1, 5MP×1, 4MP×2, 3MP×2, 1080P×4, 720P×4, 4CIF×4 |
| Third-party Camera Access | ONVIF(Profile S/T); RTSP |
| HDMI Output | 1024×768 / 1280×720 / 1280×800 / 1366×768 / 1440×900 / 1920×1080 / 3840×2160 |
| VGA Output | 1024×768 / 1280×720 / 1280×800 / 1366×768 / 1440×900 / 1920×1080 |
| Multi-screen Display | VGA: 1–10, HDMI: 1–10 |
| Audio Input | 1-ch, 3.5mm |
| Audio Output | 1-ch, RCA |
| Two-Way Audio | 1-ch, 3.5mm |
| Video Compression | S+265, H.265, S+264, H.264 |
| Audio Compression | G.711A, G.711U, ADPCM_D |
| Stream Type | Video; Video & Audio |
| Network Protocol | ARP, DDNS, DHCP, DNS, HTTP, HTTPS, ICMP, IGMP, IPv4/IPv6, NTP, RTCP, RTP, RTSP, SMTP, SSH, TCP, UDP, Unicast, UPnP |
| Mobile Client | EasyLive Plus (Android, iOS) |
| System Compatibility | CGI, SDK, P2P |
| Web | IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+ |
| Multi-channel Playback | 4 |
| Record Mode | Alarm Recording; Schedule Recording |
| Storage Method | Local HDD |
| Backup | USB storage device |
| Playback Function | Play/Pause/Stop/Slow/Speed/Backwards/Forwards/Full Screen/Backup/Digital Zoom/Instant Replay |
| Dual Stream Record | Yes |
| General Alarm | Motion Detection; Mask Alarm; Alarm Input(IPC) |
| Exceptions Alarm | Video Loss; Network Disconnected; No Disk; Illegal Access; Disk Full; Disk R/W Error; Recording Abnormal; Disk Overload; IP/MAC Conflict; RTC Failure; Voltage Alarm(IPC) |
| Intelligent Analytics | Smart Alarm; Human/Vehicle Classification; Early-warning Search |
| HDD Capacity | Up to 8 TB per HDD |
| Disk Group | 1 |
| USB | 2×USB2.0 |
| HDMI | 1×HDMI (up to 4K) |
| VGA | 1×VGA |
| Network Interface | 1×RJ-45, 10/100 Mbps |
| SATA | 1×SATA interface |
| PoE | 4×RJ45, PoE Budget 45W, 30W per port, IEEE 802.3 af/at |
| UI Language | English; Spanish; Italian; Turkish; French; Polish; Dutch; Hebrew; German; Portuguese; Greek |
| Power Supply | DC48V |
| Power Consumption | <10 W (without HDD & PoE) |
| Net Weight | 0.44 kg |
| Gross Weight | 0.86 kg |
| Dimensions | 201 × 202 × 43 mm |
| Package Dimensions | 315 × 70 × 235 mm |
| Operating Temp/Humidity | -10℃~+55℃ / 10–90% RH |
| Storage Temp/Humidity | -20℃~+60℃ / 10–90% RH |
| Package Kit | NVR, Screw Pack, Mouse, Power Adapter (DC48V 1.35A), Instructions, Parts List |
