WHX-829, -929 – building amplifier


WHX‐829 MZ5‐distr. amplifier 60V (end of line)

113.85

WHX-829 and WHX-929 amplifiers were designed for professional multimedia CATV networks where an intensive use of the return path transmission takes place.

Applied GaAs hybrid circuit guarantees high quality of signal parameters – high output level with very low inter-modulation distortions. GaAs technology enables reduction of power consumption which has an influence on reducing CATV network maintenance costs.

WHX amplifier is available in two versions: WHX-829with RF adjustment done by built-in potentiometers and WHX-929 with RF adjustment done by JXP modules.



Feature:

  • output stage amplifier based on GaAs hybrid with Power Doubler configuration,
  • high output level : 114 dBuV,
  • 1 GHz frequency range,
  • easy configuration,
  • switchable return path: passive / off / active,
  • line overvoltage protection,
  • local or remote power supply,
  • robust, die-casting aluminum housing.
