16-Port Gigabit PoE+ Switch with 2 Gigabit SFP ports 200W ( GS1020PS2 )


GS1020PS2
●IEEE 802.3af / 802.3at standard compliant
●200-watt total PoE power budget, up to 30-watt per port
●16xGbE PoE Port 2 x SFP Port
●CCTV Mode supports remote power&data feeding up to 250M
●VLAN mode supports 16 POE ports isolated from each other
●LED indicators for network diagnostics
●19-inch metal case, internal power design

DATASHEET

135.04  168.13



Model   GS1020PS2
Connector Type 16*10/100/1000M PoE Ports 2*Gigabit SFP Uplink Ports
Network Media (Cable) IEEE802.3

IEEE802.3u

IEEE802.3x

IEEE802.3ab

IEEE802.3z

PoE Parameters PoE Standard: IEEE802.3af /IEEE802.3at
Max each port: 15.4W ( IEEE 802.3af )

Max each port:30W ( IEEE 802.3at )

PoE compatibility: IEEE 802.3af/at adaptive
PoE port output: DC48-55V
Power Pin : Power over spare pairs 1/2( ) , 3/6 (-)
Network Media 10BASE-T: Cat 5E UTP(≤250 meter)

100BASE-TX: Cat5 or more UTP (≤100 meter)

1000BASE-TX: Cat5 or more UTP (≤100 meter)

Optical MultiMode Fiber: 850nm, 1310nm,  Transmission Distance: 550m/2Km

Single-Mode Fiber: 1310nm, 1550nm,  Transmission Distance: 20/40/60/80/100/120km

Performance Specification Bandwidth: 52Gbps
MAC: 8K
Packet Buffer Memory: 4M
Packet Forwarding Rate: 38.7Mpps
Power Supply Power input: AC100-240V 50/60Hz,  Power Budget: 200W
LED Indicator PWR Power supply indicator (Red) Lighting:Powered

Un-Light:No Power

1-26 RJ-45 LINK indicator (Green) Lighting:1000M Connect

Un-Light:100M or Disconnect

1-26 RJ-45 ACT indicator (Green) Lighting:Connecting

Flashing:Data Transmit

Un-Light:Disconnect

Working Environment Operating Temperature: -20℃ ~ 50℃;

Storage Temperature: -40℃ ~ 80℃;

Operating Humidity: Max 90%, non-condensing

Storage Humidity: Max 95%, non-condensing

Working Height: Max to 10,000 feet (3,000 meters)

Storage Height: Max to 10,000 feet (3,000 meters)

SKU: 7619 Categories: ,
