24-Port Layer 3 Managed Gigabit Switch with 4 10G SFP Slots (GS5024S4)
,

24-Port Layer 3 Managed Gigabit Switch with 4 10G SFP Slots (GS5024S4)

GS5024S4

253.19 € 315.24 €

Koha e arritjes së produktit : 29/03/2025 - 31/03/2025

Ein 24-GbE-, 4-SFP+-, Layer-3-Switch mit einem leisen, lüfterlosen Kühlsystem.

  •  24× GbE
  •  4× 10G SFP+
  •  Lüfterlose und geräuschlose Kühlung
  •  L3-Verwaltungsfunktionen
SKU: 7611 Categories: ,
Model Version GS5024S4 1.0
Protocols 802.3 Protocols
  • 802.3i 10 Mbps over Twisted Pair
  • 802.3u 100 Mbps over Twisted Pair
  • 802.3ab 1 Gbps over Twisted Pair
  • 802.3z 1.25 Gbps over Fiber
  • 802.3ae 10GBASE-SR/SW/LW/EW/LR/PR/ER
  • 802.3aq 10GBASE-LRM
  • 802.3x Flow Control
  • 802.3az Power Saving
  • 802.3ad Active Link Aggregation
802.1 Protocols
  • 802.1d: STP
  • 802.1s: MSTP
  • 802.1p: LAN Layer 2 Qos/Cos protocol related to traffic priority
  • 802.1q: VLAN Bridge Operation
  • 802.1s: MSTP
  • 802.1w: RSTP
  • 802.1ab: LLDP/LLDP-MED
  • 802.1x User Authentication
Memory/Storage Flash/ROM 16 MB (128 Mbit) NOR
DDR/RAM 128 MB (1 Gbit) DDR3
Interfaces Physical Buttons Reset Button
Gigabit RJ45 Ports 24
10G SFP+ Slots 4
Console Ports
  • 1× RJ45
  • 1× USB
LED
  • Power
  • System
  • Speed/Link/ACT of Each Ethernet Port
Power Input AC Inlet
Performance Copper Speed and Distance
  • Cat. 3 or higher cable: 100 meters at 10 Mbps
  • Cat. 5 or higher cable: 100 meters at 100 Mbps
  • Cat. 5e or higher cable: 100 meters at Gigabit
MAC Address Table 16384
VLANs 4096
Max Switching Capacity 128 Gbps
Max Forwarding Rate 95.232 Mpps
Jumbo Frame 12 KB
Packet Buffer 12 Mbit
Power Power Methods AC
AC 90~260V 50/60Hz
Reliability Grounding Methods
  • Three-Prong Plug
  • Grounding Point
Environment Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
General Standards
  • EMI: FCC Part 15 CISPR (EN55032) class A
  • EMS: EN61000-4-2 (ESD)
  • EN61000-4-4 (EFT)
  • EN61000-4-5 (Surge)
Package Content
  • Main Product
  • Power Cord
  • Installation Guide
  • Mounting Kit
Mechanical Installation
  • Desktop
  • Rackmount via Brackets
Casing Material Metal
Dimension 440×205×44 mm
17.32×8.07×1.73 inches
Product Weight EU: 2643 g (93.23 oz.)
Ordering Information Retail Package Dimension 500×290×85 mm
19.69×11.42×3.35 inches
Retail Package Weight EU: 3281 g (93.23 oz.)
Carton Net Weight EU: 16.4 kg (36.16 lbs)
Carton Gross Weight EU: 17.4 kg (38.36 lbs)
