UniFi Mesh Pro AP AC Outdoor


UniFi AP, AC Mesh Pro

  • 802.11 a/b/g/n/ac Wi-Fi Standards
  • 2 x 10/100/1000 Ethernet Ports
  • UniFi Controller Software
  • Integrated Omni Antennas
  • Guest Portal/Hotspot Support
  • Passive Power over Ethernet
  • 100+ Concurrent Clients
  • Reset Button
  • CE, FCC, IC Certified



With the outdoor UAP-AC-M-PRO UniFi AC Mesh Wide-Area Dual-Band Access Point from Ubiquiti Networks users benefit from a wide coverage area reaching up to 600′ along with enhanced data transfer rates of up to 1300 Mbps on the 5 GHz frequency. These enhanced data rates and coverage capabilities are supported by a 3×3 MIMO internal antenna configuration supporting multiple data paths for a more efficient end user network connection. Installation of the UAP-AC-M-PRO-US is simple as it comes 802.3af PoE compliant and includes a pole mounting kit. Once installed users can take advantage of 802.11ac Wi-Fi access with speeds of up to 1300 Mb/s in the 5 GHz radio band, and up to 450 Mb/s in the 2.4 GHz radio band.

Kodi i produktit : 0089 Kategori: , , Etiketë:
Key Specs
Wi-Fi
Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz) with MU-MIMO Support (3 x 3)
Throughput
1750 Mb/s Total
2.4 GHz: 450 Mb/s
5 GHz: 1300 Mb/s
Inputs/Outputs
2x RJ45 Gigabit Ethernet
Wireless
Wi-Fi
Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz) with MU-MIMO Support (3 x 3)
Number of Antennas
3
Antenna Gain
8 dBi
Transmit Power
22 dBm
Supported Protocols
WMM
Antenna Placement
Internal
Bluetooth
Yes
Throughput
1750 Mb/s Total
2.4 GHz: 450 Mb/s
5 GHz: 1300 Mb/s
Interface
Inputs/Outputs
2x RJ45 Gigabit Ethernet
USB Sharing Support
No
Security
Wireless Security
AES, TKIP, WEP, WPA, WPA-PSK, WPA2
Management
Supported Clients
100
Max SSIDs Supported
4
Mobile App Compatible
Yes: Android & iOS
App Name: UniFi
Functionality: Adjust Settings, Remote Control, Setup, View Live Feed
Hardware
Supported IEEE Standards
802.11i, 802.3af (PoE 15.4 W)
Electrical
DC Input Power
48 VDC
Power Consumption
9 W
Environmental
Operating Temperature
-40 to 158°F / -40 to 70°C
Operating Humidity
5 to 95%
General
Environmental Protection
No
Certifications
CE, FCC, IC
Mount Options
Pole, Wall
Dimensions
13.5 x 7.1 x 2.4″ / 34.3 x 18.1 x 6 cm
Weight
1.4 lb / 0.6 kg
Packaging Info
Package Weight
4.525 lb
Box Dimensions (LxWxH)
15.8 x 8.8 x 3.6″
