UniFi Switch 48 500W


US-48-500W – UniFi Switch, 48-Port, 500W

DATASHEET

  • 48 x PoE+ Gigabit Ethernet Ports
  • 2 x 10G SFP+ Ports
  • 2 x Gigabit SFP Ports
  • 70 Gb/s Non-Blocking Throughput
  • 140 Gb/s Switching Capacity
  • 104.16 Mpps Forwarding Rate
  • Configurable 24V Passive PoE
  • 500W Power Supply
  • Supports UniFi Controller



451.64

Grow your business’s network capacity to support computers, printers, storage, and power-over-Ethernet devices with the UniFi Switch US-48-500W 48-Port Gigabit PoE+ Compliant Managed Switch from Ubiquiti Networks. This fully managed switch features a 500W power supply, and each of its auto-sensing 48 PoE+ complaint ports provide up to 34.2W of power to 802.3af/at compatible devices such as IP cameras, VoIP phones, and access points. Alternatively, it can also be configured to provide 24V passive PoE to compatible connected devices for simplified infrastructure. With non-blocking throughput of up to 70 Gb/s at a 104.16 Mpps forwarding rate, the US-48-500W helps to ensure smooth data traffic with minimal packet loss.

The two Gigabit SFP and dual 10G SFP+ ports allow you to connect high-speed fiber line uplinks and devices to the switch for exceptional speed and versatility. Network traffic with connected devices can be further optimized using the UniFi Network Controller, which offers a comprehensive suite of features to configure, control, and monitor performance. Additionally, this switch includes a convenient rackmount kit and is designed to operate silently in the background.

Key Specs
Inputs/Outputs
48x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at)
2x SFP+ 10 GbE
2x SFP Gigabit Ethernet
1x RJ45 LAN
Switching Bandwidth
140 Gb/s
70 Gb/s (Non-Blocking)
Protocols
MAC Address Table Size
16K
Performance
Forwarding Rate
104.16 Mpps
Switching Bandwidth
140 Gb/s
70 Gb/s (Non-Blocking)
Electrical
PoE per Port
17 to 34.2 W
Power Draw
500.00 W (Active)
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Power Supply Type
Internal
Environmental
Operating Temperature
23 to 104°F / -5 to 40°C
Operating Humidity
5 to 95%
General
Certifications
No
Cooling System
Passive
Indicator Lights
Yes
Rack Mountable
Yes 1 RU
Dimensions
19.1 x 14.7 x 1.7″ / 485 x 374.6 x 43.7 mm
Weight
13.5 lb / 6.1 kg
Packaging Info
Package Weight
16 lb
Box Dimensions (LxWxH)
22.3 x 16.5 x 3.8″
