wAP LTE kit


RBwAPR-2nD&R11e-LTE with 650MHz CPU, 64MB RAM, 1xLAN, built-in 2.4Ghz 802.11b/g/n Dual Chain wireless with integrated antenna, PXA1802 LTE modem with internal LTE antenna, RouterOS L4, outdoor enclosure, PSU, PoE injector, International version

DATASHEET

103.60

Specifications

Details
Product code RBwAPR-2nD&R11e-LTE
Architecture MIPSBE
CPU QCA9531
CPU core count 1
CPU nominal frequency 650 MHz
Dimensions 185 x 85 x 30 mm
License level 4
Operating System RouterOS
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
Tested ambient temperature -40°C .. 60°C tested

Powering

Details
Max Power consumption 8W
PoE in Passive PoE
PoE in input Voltage 9-30 V
Number of DC inputs 3 (Automotive, DC jack, PoE-IN)
DC jack input Voltage 9-30 V
Automotive input Voltage 9-30 V

Mobile

Details
2G Category Class12
3G Category R7 (21Mbps Downlinks, 5.76Mbps Uplink)
LTE Category 4 (150Mbps Downlink, 50Mbps Uplink)
LTE FDD bands 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz)
LTE TDD bands 38 (2600MHz) / 40 (2300MHz)

Wireless

Details
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 2
Wireless 2.4 GHz chip model QCA9531

Ethernet

Details
10/100 Ethernet ports 1

Peripherals

Details
Number of SIM slots 1 Modem (Mini SIM)
MiniPCI-e slots 1

Other

Details
PCB temperature monitor Yes
Voltage Monitor Yes

Wireless specifications

2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 22 -96
11MBit/s 22 -89
6MBit/s 20 -93
54MBit/s 18 -74
MCS0 20 -93
MCS7 16 -71
