5MP Motorized Starlight IR Bullet Camera (TC-C35US)


TC-C35US

Spec:I8/A/E/Y/M/2.8-12mm/V4.0

176.16

·Metal housing

·Up to 5MP,2592×1944@20fps

·S+265/H.265/H.264B/H.264M/H.264H

·Color:0.002Lux@(F1.6,AGC ON),B/W:0Lux with IR

·IR range up to 80m

·Built-in Mic

·Support microSD/microSDHC/microSDXC card,up to 512GB

·Operating conditions -35℃~65℃(-31℉~149℉), ≤95%RH

·DC12V±25%,Max. 8W, PoE:IEEE 802.3af,Max. 9W

·IP67

SKU: 9027 Categories: ,
Camera
Image Sensor 1/2.8″CMOS
Min. Illumination Color:0.002Lux@(F1.6,AGC ON),B/W:0Lux with IR
Shutter Time 1s~1/100000s
Day&Night IR-cut filter with auto switch (ICR)
Smart IR Yes
WDR 120dB
S/N >42dB
Angle Adjustment 0~360°(P); 0~90°(T); 0~360°(R)
Lens
Lens Type Motorized
Focal Length 2.8~12mm
Lens Mount Φ14
Aperture Range F1.6
Aperture Type Fixed
Field of View 96.8°~32.7°(H); 71.3°~24.5°(V); 120.2°~40.9°(D)
DORI Distance W: Detect:56.0m Observe:22.2m Recognize:11.2m Identify:5.6m T: Detect:240.0m Observe:95.2m Recognize:48.0m Identify:24.0m
Illuminator
IR LEDs 4
IR Distance Up to 80m
Wavelength 850nm
Compression Standard
Video Compression S+265/H.265/H.264B/H.264M/H.264H
Video Bit Rate 32k~6Mbps
Audio Compression G.711A/G.711U/ADPCM_D
Audio  Sampling Rate 8kHz/32kHz/48kHz
Max. Resolution 5MP,2592×1944@20fps
Main Stream PAL:20fps(2592×1944), 25fps(2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720) NTSC:20fps(2592×1944), 24fps(, 2592×1520, 2560×1440), 30fps(2304×1296, 1920×1080, 1280×720)
Sub Stream PAL:25fps(704×576, 704×288, 640×360, 352×288) NTSC:30fps(704×480, 704×240, 640×360, 352×240)
BLC Yes
HLC Yes
AGC Yes
3D DNR Yes
White Balance Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance
ROI 8 rectangular static areas
OSD Overlay of additional characters in 1 regions, 1 line, with a maximum of 48 characters or 16 Chinese characters per region; 16*16/32*32/48*48/64*64
Privacy Mask 4 black static areas
Defog Yes
Feature
General Alarm Motion Detection; Mask Alarm
Exceptions Alarm Disk Full; Disk R/W Error; IP Address Conflict
Linkage Method Trigger Recording; Trigger Capture; Notify Surveillance Center; Alarm Output
Video Analytics Tripwire; Perimeter
Rules of Behavior Analyse In 1 Scene 2
Network
ANR Yes
Protocols HTTP; HTTPS; TCP/IP; UDP; UPnP; ICMP; DHCP; DNS; DDNS; Easy DDNS; NTP; TLS v1.2; QoS; IPv4; SSH; Unicast; ARP; FTP
System Compatibility P2P(Mutually exclusive with Profile G); ONVIF(Profile S/T/G) ; SDK; CGI; Milestone; RTSP
Remote Connection ≤2
Client Easy7 VMS
Moblie Client EasyLive Plus
Web IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
Interface
Communication Interface 1*RJ-45 (10/100 Base-T)
Built-in Mic Yes
Reset Button Yes
On-board Storage Support microSD/microSDHC/microSDXC card,up to 512GB
RTC Yes
General
Web Client Language 19 languages Simple Chinese/Traditional Chinese/English/Spanish/Korean/Italian/Turkish/Russian/Thai/French/Polish/Dutch/Hebrew/Arabic/Vietnamese/German/Ukrainian/Portuguese/Albanian
Operating Temperature -35℃~65℃(-31℉~149℉)
Operating Humidity ≤95%RH
Storage Temperature -35℃~65℃(-31℉~149℉)
Storage Humidity 10%~95%RH(non-condensing)
Power Supply DC12V±25%,Max. 8W; PoE:IEEE 802.3af,Max. 9W
Protection Surge4000V; ESD6000V; IP67
Boundary Dimensions 239(L)90(W)90(H)mm
Package Dimensions 280(L)125(W)140(H)mm
GrossWeight 1.28kg
