Ubiquiti airMAX LiteAP LAP-GPS AC PTMP Access Point with GPS Sync
Ubiquiti airMAX LiteAP AC PTMP Access Point with GPS Sync (LAP-GPS)
The Ubiquiti airMAX LiteAP LAP-GPS is the latest high-performance access point with disruptive pricing from Ubiquiti Networks. Featuring an ultra-lightweight form factor, the LiteAP AC is an affordable cost/performance solution for long-distance, wireless broadband bridging. The access point operates in the worldwide, license-free 5 GHz frequency range with high-performance speeds.
Ubiquiti airMAX LiteAP Key Features
- Quick Installation
- High-Performance Sector Access Point
- Up To 450 Mbps Real TCP/IP Throughput
- Lightweight, Low-Cost Solution
The LiteAP AC combines proprietary hardware and software technologies to deliver its breakthrough combination of throughput and range with cost-effective value. It also delivers up to 450 Mbps real TCP/IP throughput and features an efficient form factor.
GPS Sync Support
Precise GPS frame synchronisation enables co-located LAP-GPS devices to transmit and receive data without interfering with each other, allowing for better frequency reuse and increased network stability.
Quick Installation
Minimal fasteners simplify installation. No tools are needed; only a single wrench is required for pole-mounting.
Versatile Mounting
The ball-joint mount of the LiteAP AC provides adjustment flexibility for versatile mounting options.
Efficient Design
The LiteAP AC features a lightweight antenna with an integrated radio in a sleek design.
Gigabit Ethernet
The LiteAP AC delivers high throughput over its wired connection.
Deployment Example
Ubiquiti airMAX LiteAP Technical Specifications
General
- Dimensions (Mount Not Included): 360.98 x 124.57 x 71.28 mm (14.21 x 4.90 x 2.81″)
- Weight (No Mount): 752 g (1.66 lb)
- Mounting Kit: Pole Mounting Kit (Included)
- Networking Interface: 1 x 10/100/1000 Ethernet Port
- Memory: DDR2 64 MB
- Max. Power Consumption: 7.1W
- Max. TX Power: 25 dBm
- Antenna Gain: 17 dBi
- Power Supply: 24V, 0.3A PoE Adapter (Included)
- Power Method: Passive PoE (Pairs 4, 5 ; 7, 8 Return)
- Processor Specs: Atheros MIPS 74Kc, 533 MHz
- Shock and Vibration: ETSI300-019-1.4
- ETSI Specification: EN 302 326 DN2
- ESD/EMP Protection: ± 24 kV Contact / Air
- RoHS Compliance: Yes
- Operating Temperature: -40 to 70° C (-40 to 158° F)
- Operating Humidity: 5 to 95% Noncondensing
- Certifications: FCC, IC, CE
