General
- Dimensions: 358 x 271.95 x 272.5 mm (14.09 x 10.71 x 10.73″)
- Weight:
– Without Mount: 800 g (1.76 lb)
– With Mount: 980 g (2.16 lb) - Power Supply: 24V, 0.3A Gigabit PoE Adapter (Included)
- Max. Power Consumption: 7W
- Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
- Supported Voltage Range: 24V ± 10%
- Gain: 23 dBi
- Networking Interface: (1) 10/100/1000 Ethernet Port
- Processor Specs: MIPS 74Kc
- Memory: 64 MB DDR2
- LEDs: Power, Ethernet
- Channel Sizes:
– PtP Mode: 10/20/30/40/50/60/80 MHz
– PtMP Mode: 10/20/30/40 MHz - Enclosure Characteristics: Reflector (SGCC 0.6T) / Plastic: PC
- Mounting: Pole-Mounting Kit (Included)
- Wind Loading: 275 N @ 200 km/h (61.8 lbf @ 125 mph)
- Wind Survivability: 200 km/h (125 mph)
- ESD/EMP Protection: ± 24 kV Contact / Air
- Operating Temperature: -40 to 70° C (-40 to 158° F)
- Operating Humidity: 5 to 95% Noncondensing
- Certifications: CE, FCC, IC
