UniFi 6 Mesh


U6-MESH

DATASHEET

  • Wi-Fi 6 (802.11ax)
  • Up to 5374 Mb/s Throughput
  • 2.4 GHz / 5 GHz (Dual-Band)
  • 1 x Gigabit Ethernet PoE Port
  • IPX5 Rated
  • Wall & Pole Mounting Kits Included
  • Up to 150

226.00

Quickly expand your business’s wireless network coverage with the U6-Mesh Wireless Dual-Band Wi-Fi 6 Mesh Outdoor Access Point from Ubiquiti Networks. Designed for outdoor installations, this 802.11ax access point is IPX5 rated for weather resistance and can withstand temperatures between -22° and 140°F. With support for the 160 MHz channel, customers, employees, and clients can transfer up to 4.8 Gb/s over the 5 GHz band and 574 Mb/s through the 2.4 GHz frequency with compatible devices.

This access point is designed to handle over 300 concurrent users with up to 1500 ft2 coverage. Use the included PoE adapter to power the access point through its Gigabit Ethernet uplink port. Wall and pole mounting kits are included for flexible positioning. The U6-Mesh-US Wireless Dual-Band Wi-Fi 6 Mesh Outdoor Access Point may be managed with the UniFi Network application v6.3.51 and later.

Wireless
Wireless
Wi-Fi 6 (802.11ax)Bluetooth
Wi-Fi
Wi-Fi 6 (802.11ax) with MU-MIMO Support (4 x 4)
Antenna Gain
3 to 5 dBi
Matter Support
No
Communication Protocol
No
Bluetooth
Yes
Performance
Throughput
5374 Mb/s Total
5 GHz: 4800 Mb/s
2.4 GHz: 574 Mb/s
Interface
Inputs/Outputs
Satellite:
1x RJ45 Gigabit Ethernet (WAN) PoE
Security
Wireless Security
WPA-PSK, WPA-Enterprise, WPA2-PSK, WPA2-Enterprise, WPA3-PSK, WPA3-Enterprise
Management
Operation Modes
Access Point
Virtual Assistant
No
Mobile App Compatible
Yes: Android & iOS
Hardware
Supported IEEE Standards
802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n, 802.1q, 802.3af (PoE 15.4 W)
Electrical
DC Input Power
57 VDC
Power Consumption
11.4 W
Environmental
Operating Temperature
2 to 92°F / -30 to 60°C
Operating Humidity
5 to 95%
General
Environmental Protection
Water-Resistant (IPX5)
Dimensions
6.3 x 1.9 x 1.9″ / 159.5 x 48.5 x 48.5 mm
Weight
14.1 oz / 400 g
Packaging Info
Package Weight
2.21 lb
Box Dimensions (LxWxH)
7.4 x 5.6 x 3.7″
