Deploy UniFi AC HD AP in high-density environments requiring maximum wireless performance. The UniFi AC HD AP features simultaneous dual-band, 4×4 MU-MIMO technology and convenient 802.3at PoE compatibility. The Wave 2 MU-MIMO technology allows the AP to communicate with multiple clients at the same time – significantly increasing multi-user throughput and overall user experience. The UniFi AC HD AP is the first UniFi 802.11ac Wave 2 AP. It combines the performance increases from MU-MIMO technology and the use of 4×4 spatial streams to deliver up to 125% greater performance than a typical Wave 1 AP.
At any single time, a Wave 2 AP can communicate with the following MU-MIMO clients:
• Four 1×1 clients
• Two 2×2 clients
• One 2×2 clients and two 1×1 clients
• One 3×3 clients and one 1×1 client
Product Features
• Radio Hardware Acceleration: Independent 2.4GHz and 5GHz dedicated hardware offload for maximized multi-user throughput and reduced latency
• CPU Hardware Acceleration: Dedicated hardware offload for QoS, Guest Control, and Client Management
• Optimized for MU-MIMO: Genetically optimized antenna arrays for maximal utilization of 802.11ac Wave 2 MU-MIMO Beam Forming
• Beam Forming: Data is sent and received using multiple antennas to increase throughput and range
Product Specifications
• Dimensions: 220 x 220 x 49.1mm (8.66 x 8.66 x 1.89″)
• Weight: 700g (1.54lbs)
• Weight w/ Mounting Kits: 830g (1.83lbs)
• Networking Interface: (2) 10/100/1000 Ethernet Ports
• Buttons: Reset
• Power Method: Passive Power over Ethernet (48V), 802.3at PoE Supported
• Supported Voltage Range: 44 to 57VDC
• Power Supply: 48V, 0.5A PoE Gigabit Adapter
• Power Save: Supported
• Maximum Power Consumption: 17W
• TX Power:
2.4GHz: 6-25dBm
5GHz: 6-25dBm
• Antennas:
2.4GHz: (2) Dual-Port, Dual-Polarity Antennas, 3dBi each
5GHz: (2) Dual-Port, Dual-Polarity Antennas, 4dBi each
• Wi-Fi Standards: 802.11 a/b/g/n/ac/ac-wave2
• Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
• BSSID: Up to Four per Radio
• Mounting: Wall/Ceiling (Kits Included)
• Operating Temperature: -10 to 70°C (14 to 158°F)
• Operating Humidity: 5 to 95% non-condensing
• Certifications: CE, FCC, IC
Advanced Traffic Management
• VLAN: 802.1Q
• Advanced QoS: Per-User Rate Limiting
• Guest Traffic Isolation: Supported
• WMM: Voice, Video, Best Effort, and Background
• Concurrent Clients: 500
Supported Data Rates (Mbps)
• 802.11a: 6, 9, 12,18, 24, 36, 54 Mbps
• 802.11n: 6,5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)
• 802.11ac: 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80)
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
UBIQUITI DATASHEET
