2MP Fixed Bullet Camera (TC-C321n I3/E/Y/2.8mm )
29.79 €
TC-C321n
Spec: I3/E/Y/2.8mm
Specifications
| Category | Specification |
|---|---|
| Image Sensor | 1/2.9" CMOS |
| Minimum Illumination | Color: 0.02 lux @ (F2.0, AGC ON); B/W: 0 lux with IR |
| Shutter Time | 1 s ~ 1/100000 s |
| Day & Night | IR-cut filter with auto switch (ICR) |
| Smart IR | Yes |
| WDR | DWDR |
| S/N Ratio | > 37 dB |
| Angle Adjustment | Pan: 0~360°; Tilt: 0~80°; Rotate: 0~360° |
| Lens Type | Fixed focal lens |
| Focal Length | 2.8 mm |
| Lens Mount | M12 |
| Aperture Range | F2.0 |
| Aperture Type | Fixed |
| Field of View | H: 102.8°; V: 57.6°; D: 117.8° |
| DORI Distance | Detect: 40.0 m; Observe: 15.9 m; Recognize: 8.0 m; Identify: 4.0 m |
| IR LEDs | 2 |
| IR Distance | Up to 30 m |
| IR Wavelength | 850 nm |
| Video Compression | S+265 / H.265 / H.264B / H.264M / H.264H |
| Video Bit Rate | 32 kbps ~ 4 Mbps |
| Audio Compression | G.711A / G.711U |
| Audio Sampling Rate | 8 kHz |
| Maximum Resolution | 2 MP (1920 × 1080) @ 30 fps |
| Main Stream | PAL: 25 fps (1920×1080, 1280×720, 704×576, 640×480); NTSC: 30 fps (1920×1080, 1280×720, 704×480, 640×480) |
| Sub Stream | PAL: 25 fps (704×576, 704×288, 640×360, 352×288); NTSC: 30 fps (704×480, 704×240, 640×360, 352×240) |
| BLC / HLC / AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto / Semi-Auto / Manual / Sunshine / Nature Light / Warmlight Lamp / Daylight Lamp / Filament Lamp / Lock |
| OSD | 1 region, 1 line; up to 48 characters or 16 Chinese characters; font sizes 16×16 ~ 48×48 |
| Privacy Mask | 4 static black areas |
| Defog | Yes |
| General Alarm | Motion Detection |
| Exception Alarm | IP address conflict |
| Protocols | HTTP; TCP/IP; UDP; ICMP; DHCP; DNS; NTP; TLS v1.2; IPv4; Telnet; Unicast |
| System Compatibility | ONVIF (Profile S/T); SDK; CGI; Milestone; RTSP |
| Remote Connection | ≤ 2 |
| Client Software | Easy7 VMS |
| Web Browser | IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+ |
| Network Interface | 1 × RJ45 (10/100 Base-T) |
| Built-in Microphone | Yes |
| Web Client Language | English |
| Operating Temperature | -30°C ~ 60°C |
| Operating Humidity | ≤ 95% RH |
| Storage Temperature | -30°C ~ 60°C |
| Storage Humidity | 10% ~ 95% RH (non-condensing) |
| Power Supply | PoE IEEE 802.3af |
| Power Consumption | Max. 6 W |
| Protection | Surge 4000 V; ESD 6000 V; IP67 |
| Dimensions | 164 × 73 × 73 mm |
| Package Dimensions | 180 × 90 × 95 mm |
| Gross Weight | 0.3 kg |
DATASHEET
